Keysight Technologies E4360 Series User Manual

1 General Information
12 Series E4360 User’s Guide
The Front Panel - At a Glance
Display
Turns off after 1 hour of inactivity.
Press any key to restore the display.
Navigation keys
Move the cursor to a menu item.
Select the highlighted menu item.
Ou t put keys
Turn the outputs on or off.
Enter voltage or current.
50.007V 4.004A
CV Set: 50.000V 5.500
A
o -
Menu
3
E
+/-
Back
.
2
0
1
4 5 6
987
Sel
Meter
Channel
Help
On/Off
Voltage
Current
1
Error
Enter
Modular SAS
Mainframe
600
Watt
E4360A
On/Off switch and LED
LED indicates power is on.
Green = normal operation.
Amber = display is screen-saver mode.
Sy stem keys
Toggle between single-channel and
multiple-channel view.
Access front panel command menu.
Select an output channel to control.
N u meric entry keys
Enter values.
Increment or decrement
values.
Keysight E4360J01
Display
Turns off after 1 hour of inactivity.
Press any key to restore the display.
Navigation keys
Move the cursor to a menu item.
Select the highlighted menu item.
Ou t put keys
Turn the outputs on or off.
Enter voltage or current.
CV Set: 40.000V 2.000
A
o -
Menu
3
E
+/-
Back
.
2
0
1
4 5 6
987
Sel
Meter
Channel
Help
On/Off
Voltage
Current
1
Error
Enter
Modular SAS
Mainframe
600
Watt
E4360J01
40.007V 1.804A
On/Off switch and LED
LED indicates power is on.
Green = normal operation.
Amber = display is screen-
saver mode.
Sy stem keys
Toggle between single-channel and
multiple-channel view.
Access front panel command menu.
Select an output channel to control.
N u meric entry keys
Enter values.
Arrow keys increment or
decrement voltage and
current settings.
