106 Keysight E5061B Network Analyzers
Post-Repair Procedures
Post-Repair Procedures
5-
A9 LF Source
Bias Module
Perform the following required
adjustments using “A9 Bias Module” in
Spot Adjustment of the program.
“To Execute the Diagnostic Test” on
page 33
Frequency Accuracy Test
RF Output Level Accuracy and Flatness Test
RF Output Level Linearity Test
Trace Noise Test
Crosstalk & System Dynamic Range Test
Dynamic Accuracy Test
Uncorrected System Performance Test
LF Output Level Accuracy Test (Opt 3L5)
LF Output Level Linearity Test (Opt 3L5)
Input Impedance Test (Opt 3L5)
Absolute Amplitude Accuracy Test (Opt 3L5)
Magnitude Ratio/Phase Frequency
Response Test (Opt 3L5)
Trace Noise Test (Opt 3L5)
Crosstalk and Noise Level Test (Opt 3L5)
Magnitude Ratio/Phase Dynamic Accuracy
Test (Opt 3L5)
DC Measurement Accuracy Test (Opt 3L5)
A10 Analog
Motherboard
No adjustment needed Inspect the Booting Process
When the symptom of failure is out of
specification, perform the performance test.
A50 CPU module No adjustment needed Inspect the Booting Process
DSP Card Perform the following required
adjustments using “A51 DSP board” in
Spot Adjustment of the program.
Writing ID
Inspect the Booting Process
Executed all of the performance test.
“To Check the Front Panel” on
page 42
“To Check the External Trigger Input”
on page 44
Front Panel
Board
No adjustment needed “To Check the Front Panel” on
page 42
Table 5-1 Post-Repair Procedures (Option 3L5)
Replaced
Assembly or Part
Required Adjustments
Correction Constants (CC)
Verification
