108 Keysight E5061B Network Analyzers
Post-Repair Procedures
Post-Repair Procedures
5-
A3/A4 Receiver
Module
Perform the following required
adjustments using “A3/A4 Receiver
Module” in Spot Adjustment of the
program.
“To Execute the Diagnostic Test” on
page 33
Frequency Accuracy Test
RF Output Level Accuracy Test
RF Output Level Linearity Test
Crosstalk & System Dynamic Range Test
Noise Floor Test
Trace Noise Test
Dynamic Accuracy Test
Compression Test
IF Linearity at 1.195 GHz Test
IF Linearity at LF Test
Uncorrected System Performance Test.
A10 Analog
Motherboard
No adjustment needed Inspect the Booting Process
When the symptom of failure is out of
specification, perform the performance test.
A50 CPU module No adjustment needed Inspect the Booting Process
DSP Card Perform the following required
adjustments using “DSP board” in Spot
Adjustment of the program.
Writing ID
Inspect the Booting Process
Executed all of the performance test.
“To Check the Front Panel” on
page 42
“To Check the External Trigger Input”
on page 44
Front Panel
Board
No adjustment needed “To Check the Front Panel” on
page 42
Handler I/O
Board
No adjustment needed “To Execute the Diagnostic Test” on
page 33
HDD Perform “HDD” (Hard Disk Drive) in Spot
Adjustment of the program.
Calibration of the Touch Screen (for opt.
016)
Inspect the Booting Process
Power Supply
Assembly
No adjustment needed Inspect the Booting Process
Table 5-2 Post-Repair Procedures
Replaced
Assembly or Part
Required Adjustments
Correction Constants (CC)
Verification
To Next Page
