Settings Sample Points 256k, 128k, 64k, 32k,
16k, 8192, 4098,
2048, or 1024
Specifies the number of points in a scope trace. Default is 4096.
Action required:
Press Sample Points to view and select the nine available sample points.
Time Reference Lf, Ctr or Rg Specifies the reference point on the display.
This is the position of the trigger if no offset has been set.
Default is Lf.
Action required:
Press Time Ref to toggle between Lf, Ctr and Rg.
Lf (Left) Lets you see the waveform after the trigger event.
Ctr (Center) Lets you see the waveform before and after the trigger event.
Rg (Right) Lets you see the waveform up to the trigger event
Trigger Source V<1-2> Level, I<1-2>
Level, List Key,
On/Off, DIO or
Remote
Configures the trigger source.
Default is Key.
Action required:
Press Trigger Source to select a trigger source. This trigger source will trigger the
scope measurements on all input channels.
V<1-2> Level Selects the voltage trigger level as trigger source.
Triggers the measurement when the voltage of the
corresponding input passes through the specified level.
I<1-2> Level Selects the current trigger level as trigger source.
Triggers the measurement when the current of the
corresponding input passes through the specified level.
List Key (List Run-
/Stop Key)
Selects the List Run/Stop key as a trigger source.
On/Off (Input
On/Off Key)
Selects the Input On/Off keys as a trigger source. Also applies
to the All Inputs On/Off key.
IO (DIO Trigger In) Selects any configured digital IO (with Trigger Input function)
as a trigger source.
Remote (Remote
Command)
Selects a remote interface command as a trigger source.
124
Keysight EL30000 Series User's Guide
