Store Settings
Store Settings creates folders and files (.csv format) to store the instrument's state to the external memory, or to
store the instrument's state to the internal memory.
Destination: Int allows you to store an instrument's state in the instrument's internal memory. You can store up to
10 separate states in the internal memory and set any one of them as the power-on state.
Menu Available settings Description
Action: Store, Folder Allows you to either store an instrument's state or to create a new folder.
Dest.: Int, Ext Selects whether you want to store an instrument's state in the internal or external memory.
– Internal: The instrument's state is stored in the instrument's internal memory.
– External: The instrument's state is stored in the external USB drive.
Store in State 0 to State 9 Selects the state number to store the instrument's state.
Set PwrOn Yes, No Select 'Yes' to load the selected stored state upon power-on.
Store - Stores the state.
Destination: Ext allows you to store an instrument's state in the external USB drive inserted in the front panel's USB
port. You can specify the path and filename of the stored state.
Menu Available settings Description
Action: Store, Folder Allows you to either store an instrument's state or to create a new folder.
Dest.: Int, Ext Selects whether you want to store an instrument's state in the internal or external memory.
– Internal: The instrument's state is stored in the instrument's internal memory.
– External: The instrument's state is stored in the external USB drive.
Browse - Allows you to browse and specify the location of the external memory to save the state.
Filename Specifies the filename. Use the virtual keyboard to enter your desired filename.
Store - Stores the state.
128
Keysight EL30000 Series User's Guide
