Product Introduction
The EL30000 Series DC electronic loads are designed with superior performance in compact bench form factor.
Ideal for design/verification of consumer power supplies, batteries, battery modules, solar panels, LED drivers, as
well power converters.
The series includes single and dual inputs models:
– EL33133A: Single Input DC Electronic Load; 150 V, 40 A, 250 W
– EL34143A: Single Input DC Electronic Load; 150 V, 60 A, 350 W
– EL34243A: Dual Input DC Electronic Load; 2 x 150 V, 60 A, 300 W (total 600 W)
Features:
Clean, reliable load
– 250350 to 600 W, 0 to150 V, 0 to 60 A
– Four modes: constant voltage (CV), constant current (CC), constant power (CP), and
constant resistance (CR)
– Excellent programming/readback accuracy
– High resolution
– 2-wire or 4-wire remote sense
– Over voltage, over current, and over temperature protection
Convenient benchtop capabilities
– Dynamic transient response up to 100 kHz
– Thermal-control fan speed for lower acoustic noise
– Input parallel connections (EL34243A only)
– Front and rear input terminal
Intuitive and easy to use interfaces
– 4.3-inch LCD color display
– Color-coded channels
– Individual knobs for voltage and current input
– LAN (LXI), USB, and GPIB (optional)
Advance characterization
– Scope view
– Data logging
– Input sequencing
– Low range current measurement
– Adjustable voltage slew rate
