312 Keysight N9927-90001 User’s Guide
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2
Only)
How to Set Up Over–the–Air (OTA) Mode Settings
7. Press Back >Back
Playing a Recorded Log and Viewing the Data
To play the log results:
1. Press Playback
> Recall Logs
And, use the Use the RPG or the arrow keys to highlight the file to be
played.
2. Press Recall File
>Play
3. Optional: Press Scale/Ampltd
Then choose:
— Optional (Bar Chart and Spectrum only): To adjust the following, use
the RPG (fine adjust) or the arrow keys (coarse adjust) to
change the color bar.
— Ref Level
to change the top reference position in the Bar
Chart, Strip Chart, and Spectrum.
— Red Limit
to change the color bar.
— Blue Limit
to change the color bar.
4. Press Stop
to exit the log playing.
To pause the log play:
1. Press Pause Resume
to pause or resume the log playing.
— Optional: When the recording is paused, press PlayTrace ID
to
specify the trace number of the recorded data log to display when
playback is paused.
2. Press Stop
to stop the log playing.
Save 5: Save the Log Results:
Two file types are supported for save or recall log results:
—KML file format
— Files stored in this format can be imported into 3rd party applications
like Google Earth or Google Maps.
— CSV file format. Files stored into this format can be imported into
spreadsheet applications.
Procedure:
1. Press When done press Stop
.
