Keysight N9927-90001 User’s Guide 447
Built-in Power Meter Mode – Option 310
Built-in Power Meter Settings
Built-in Power Meter Settings
Select Built-in Power Meter Mode before making any setting in this section.
How to select Built-in Power Meter Mode
—Press Mode
—Then More
—Then Power Meter (Built-in)
Frequency/ Span / Step
Valid Built-in Power Meter measurements can be made over the entire
frequency range of the FieldFox. Although it is possible to enter a center
frequency below the FieldFox minimum frequency, the LO feed-thru of the
internal SA hardware will invalidate these Built-in Power Meter measurements.
The measurement span (also known as Channel Width and Integration BW) is
the frequency range, half above and half below the center frequency, over
which power is detected and displayed. The maximum measurement span is
100 MHz.
How to enter center frequency, step size, and span
The default frequency is 50 MHz.
—Press Freq/Dist
—Then Center
— Then type a value using the numeric keypad. Then press a multiplier key.
Learn about multiplier abbreviations “Multiplier Abbreviations” on page 43.
The current frequency (f) is shown on the FieldFox screen.
— Optionally, use the arrows or rotary knob to quickly change Center
frequency. The size of the frequency step can also be changed. Press CF
Step then type a step size value using the numeric keypad, then select a
multiplier key.
— Optionally press Span
Type a value using the numeric keypad. Then press a
multiplier key. The default span is 20 MHz. The maximum span is 100 MHz.
The current span setting is shown as the dividend in the digital display. For
example: -10 dBm / 1.00 MHz
Please observe the SA RF Input port damage level.
+27 dBm (320 mW) average
+33 dBm peak (2 W) <10μs
+50 VDC
