472 Keysight N9927-90001 User’s Guide
Pulse Measurements Mode – Option 330
Pulse Measurement Settings
Pulse Measurement Settings
Select Pulse Measurement Mode before making any setting in this section.
How to select Pulse Measurement Mode
—Press Mode
—Then More if your FieldFox contains more than five measurement modes.
—Then Pulse Measurements
Measurement Selection
The pulse measurement results are presented as either a traditional power
meter display or as a trace graph.
How to select the Measurement
—Press Measure 1
— Then choose from the following:
— Average
Average power (Meter display)
— Peak
Peak power (Meter display)
— Pk to Avg
Displays the difference between the above two
measurements (Meter display)
— Trace Graph
(default) The primary trace (Tr 1) plots pulse data in
amplitude versus time. Optionally, you can enable a secondary
‘zoom’ trace. Learn how in “Zoom Window” on page 473.
— When a ‘Meter display’ measurement is selected, the following Pulse
Measurement Mode settings are identical to the standard USB Power
Meter Mode settings.
—Learn how to set Scale in “Scale” on page 474.
—Learn how to set Relative and Offset Power in “Relative and Offset
Power Measurements” on page 456.
—Learn how to set Display Units in “Display Units” on page 456.
—Learn how to set Limits in “Limits” on page 458.
Frequency / Time
How to set Frequency
—Press Freq/Dist
— Then choose from the following:
