24 Keysight InfiniiVision 1000 X-Series Oscilloscopes User's Guide

1 Getting Started

8. Run Control

keys

When the [Run/Stop] key is green, the oscilloscope is running, that is, acquiring data when trigger

conditions are met. To stop acquiring data, press [Run/Stop].

When the [Run/Stop] key is red, data acquisition is stopped. To start acquiring data, press

[Run/Stop].

To capture and display a single acquisition (whether the oscilloscope is running or stopped), press

[Single]. The [Single] key is yellow until the oscilloscope triggers.

For more information, see "Running, Stopping, and Making Single Acquisitions (Run

Control)" on page 34.

9. Measure

controls

The measure controls consist of:

•[Analyze] key — Press this key to access analysis features like trigger level setting, measurement

threshold setting, Video trigger automatic set up and display, or digital voltmeter (see "Digital

Voltmeter" on page 74).

•[Meas] key — Press this key to access a set of predefined measurements. See

"Measurements" on page 65.

•[Cursors] key — Press this key to open a menu that lets you select the cursors mode and source.

• Cursors knob — Push this knob select cursors from a popup menu. Then, after the popup menu

closes (either by timeout or by pushing the knob again), rotate the knob to adjust the selected

cursor position.

10. Tools keys The Tools keys consist of:

•[Save/Recall] key — Press this key to save oscilloscope setups, screen images, waveform data, or

mask files or to recall setups, mask files or reference waveforms. See "Save/Recall (Setups,

Screens, Data)" on page 84.

• [Utility] key — Press this key to access the Utility menu, which lets you configure the

oscilloscope's I/O settings, use the file explorer, set preferences, access the service menu, and

choose other options. See "Utility Settings" on page 88.

• [Display] key — Press this key to access the menu where you can enable persistence, adjust the

display grid (graticule) intensity, label waveforms, add an annotation, and clear the display (see

"Display Settings" on page 49).

• [Quick Action] key — Press this key to perform the selected quick action: measure all snapshot,

print, save, recall, freeze display. and more. See "Configuring the [Quick Action] Key" on

page 90.

•[Save to USB] key — Press this key to perform a quick save to a USB storage device.
