Horizontal Controls
Horizontal Knobs and Keys
Horizontal Softkey Controls
The following figure shows the Acquire menu which appears after pressing the
[Acquire] key.
Trigger
point
Time
reference
Delay
time
Time/
div
Trigger
source
Trigger level
or threshold
XY or Roll
mode
Normal
time mode
Zoomed
time base
Time
reference
