48 Keysight InfiniiVision 1000 X-Series Oscilloscopes User's Guide

2 Quick Reference

Reference Waveforms

Analog channel or math waveforms can be saved to one of two reference

waveform locations in the oscilloscope. Then, a reference waveform can be

displayed and compared against other waveforms. One reference waveform can

be displayed at a time.

Table 11 Reference Waveform Features

Feature Front Panel Key/Softkey Location (see built-in help for more information)

Reference waveforms,

display

[Ref] > Display Ref

Reference waveforms,

save

[Ref] > Save/Clear > Source, [Ref] > Save/Clear > Save to

Reference waveforms,

skew

[Ref] > Skew, Entry knob

Reference waveforms,

scale

[Ref] > Scale, Entry knob

Reference waveforms,

offset

[Ref] > Offset, Entry knob

Reference waveforms,

clear

[Ref] > Save/Clear > Clear

[Save/Recall] > Default/Erase > Secure Erase

Reference waveforms,

info

[Ref] > Save/Clear > Display Info

Reference waveforms,

info, transparent

background

[Ref] > Save/Clear > Transparent

Reference waveforms,

save/recall from USB

storage device

[Save/Recall] > Save > Format, Reference Waveform data (*.h5)

[Save/Recall] > Recall > Recall:, Reference Waveform data (*.h5)
