Keysight InfiniiVision 1000 X-Series Oscilloscopes User's Guide 77
Waveform Generator
On G-suffix oscilloscope models, a waveform generator is built into the
oscilloscope. The waveform generator gives you an easy way to provide input
signals when testing circuitry with the oscilloscope.
Waveform generator settings can be saved and recalled with oscilloscope setups.
See "Save/Recall (Setups, Screens, Data)" on page 84.
Table 23 Waveform Generator Features
Feature Front Panel Key/Softkey Location (see built-in help for more information)
Waveform generator
waveform type
[Wave Gen] > Waveform (Sine, Square, Ramp, Pulse, DC, Noise)
Waveform generator
expected output load
[Wave Gen] > Settings > Output Load (50
Ω, High-Z)
Waveform generator
logic presets
[Wave Gen] > Settings > Logic Presets > (TTL, CMOS 5.0V, CMOS 3.3V, CMOS 2.5V, ECL)
Invert shape of
waveform
[Wave Gen] > Settings > Invert Output
Add noise to output [Wave Gen] > Settings > Add Noise
Modulation,
enable/disable
[Wave Gen] > Settings > Modulation > Modulation
AM modulated output [Wave Gen] > Settings > Modulation > Type, Amplitude Modulation (AM)
FM modulated output [Wave Gen] > Settings > Modulation > Type, Frequency Modulation (FM)
FSK modulated output [Wave Gen] > Settings > Modulation > Type, Frequency-Shift Keying Modulation (FSK)
Restore waveform
generator defaults
[Wave Gen] > Settings > Default Wave Gen
