Keysight Technologies InfiniiVision 1000 X-Series User Manual

6 Keysight InfiniiVision 1000 X-Series Oscilloscopes User's Guide
In This Guide
This guide shows how to use the InfiniiVision 1000 X-Series oscilloscopes.
When unpacking and using the
oscilloscope for the first time, see:
• Chapter 1, “Getting Started,” starting on page 13
When displaying waveforms and
acquired data, see:
• "Running, Stopping, and Making Single
Acquisitions (Run Control)" on page 34
• "Horizontal Controls" on page 35
• "Vertical Controls" on page 38
• "Analog Bus Display" on page 41
• "FFT Spectral Analysis" on page 42
• "Math Waveforms" on page 46
• "Reference Waveforms" on page 48
• "Display Settings" on page 49
When setting up triggers or changing
how data is acquired, see:
• "Triggers" on page 52
• "Acquisition Control" on page 56
Making measurements and analyzing
data:
• "Cursors" on page 63
• "Measurements" on page 65
• "Mask Testing" on page 67
• "Digital Voltmeter" on page 74
• "Frequency Response Analysis" on page 75
When using the built-in waveform
generator, see:
• "Waveform Generator" on page 77
When using licensed serial bus
decode and triggering features, see:
• "Serial Bus Decode/Trigger" on page 78
When saving, recalling, or printing,
see:
• "Save/Recall (Setups, Screens, Data)" on page 84
• "Print (Screens)" on page 87
