Keysight InfiniiVision 1000 X-Series Oscilloscopes User's Guide 81
When interpreting the decode waveforms, see the Mode softkey built-in help.
SPI Decode/Trigger
On DSOX1000-Series oscilloscopes, the SPI serial decode and triggering option
can be enabled with the EMBD license.
When interpreting the decode waveforms, see the Mode softkey built-in help.
Table 27 LIN Decode/Trigger Features
Feature Front Panel Key/Softkey Location (see built-in help for more information)
LIN signal setup After selecting the Serial Bus and the LIN serial bus mode, press [Bus] > Signals > to open the LIN
Signals menu. In this menu, you can select the oscilloscope source channel probing the signal and
the appropriate threshold voltage to use when decoding/triggering the signal, as well as other signal
options.
LIN baud rate
[Bus] > Signals > Baud > Baud, Entry knob
LIN sample point
[Bus] > Signals > Sample Point, Entry knob
LIN standard
[Bus] > Signals > Standard, Entry knob (LIN 1.3, LIN 2.X)
LIN sync break
[Bus] > Signals > Sync Break, Entry knob (>= 11, >= 12, >= 13)
LIN show parity [Bus] > Show Parity
LIN trigger [Trigger] > Trigger Type, Serial 1 (LIN)
[Trigger] > Trigger on: (Sync - Sync Break, ID - Frame ID, ID & Data - Frame ID and Data, Parity Error,
Checksum Error)
For triggers where you can specify frame ID or data values, there are additional softkeys you can use
to enter the values.
