80 Keysight InfiniiVision 1000 X-Series Oscilloscopes User's Guide
2 Quick Reference
I2C Decode/Trigger
On all 1000 X-Series oscilloscopes, the I2C serial decode and triggering option
can be enabled with the EMBD license.
When interpreting the decode waveforms, see the Mode softkey built-in help.
LIN Decode/Trigger
On DSOX1000-Series oscilloscopes, the LIN serial decode and triggering option
can be enabled with the AUTO license.
CAN trigger [Trigger] > Trigger Type, Serial 1 (CAN)
[Trigger] > Trigger on: (SOF - Start of Frame, Remote Frame ID (RTR), Data Frame ID (~RTR), Remote
or Data Frame ID, Data Frame ID and Data, Error Frame, All Errors, Acknowledge Error, Overload
Frame)
For triggers where you can specify frame ID or data values, press [Trigger] > Bits > to open the CAN
Bits menu where you can enter the values.
Table 25 CAN Decode/Trigger Features (continued)
Feature Front Panel Key/Softkey Location (see built-in help for more information)
Table 26 I2C Decode/Trigger Features
Feature Front Panel Key/Softkey Location (see built-in help for more information)
I2C signal setup After selecting the Serial Bus and the I2C serial bus mode, press [Bus] > Signals > to open the I2C
Signals menu. In this menu, you can select the oscilloscope source channels probing the serial clock
and serial data signals. You can also specify the appropriate threshold voltages to use when
decoding and triggering on the signals.
I2C address size [Bus] > Addr Size (7 Bit, 8 Bit)
I2C trigger [Trigger] > Trigger Type, Serial 1 (I2C)
[Trigger] > Trigger on: (Start Condition, Stop Condition, Missing Acknowledge, Address with no Ack,
Restart, EEPROM Data Read, Frame (Start: Addr7: Read: Ack: Data), Frame (Start: Addr7: Write: Ack:
Data), Frame (Start: Addr7: Read: Ack: Data: Ack: Data2), Frame (Start: Addr7: Write: Ack: Data: Ack:
Data2), 10-bit Write)
For triggers where you can specify address or data values, there are additional softkeys you can use
to enter the values.
