30 Keysight InfiniiVision 1000 X-Series Oscilloscopes User's Guide
1 Getting Started
Softkey labels and
information area
When most front panel keys are pressed, short menu names and softkey labels appear in this area.
The labels describe the softkey functions. Typically, softkeys let you set up additional parameters for
the selected mode or menu.
Pressing the Back key returns through the menu hierarchy until softkey labels are off and the
information area is displayed. The information area contains acquisition, analog channel, math
function, and reference waveform information.
You can also specify that softkey menus turn off automatically after a specified timeout period
([Utility] > Options > Menu Timeout).
Pressing the Back key when the information area is displayed returns to the most recent menu
displayed.
Measurements area When measurements or cursors are turned on, this area contains automatic measurement and cursor
results.
When measurements are turned off, this area displays additional status information describing
channel offset and other configuration parameters.
