As displayed in Figure 5 on page -21, the M8045A module has the
following components.
Table 3 Insertion/Extraction and Retaining
Table 4 Front Panel LEDs
Component Description
Retaining screws The screws on both ends of the module are used to retain the module tightly
inside the M9505A AXIe Chassis slot once you have fully placed it inside the
chassis. To remove the module, you first need to loosen these screws ensuring
that these screws disengage completely.
Module Insertion/Extraction
Handles
The handles on both sides of the module to insert or eject the module from the
slot of the M9505A AXIe Chassis.
Connector Name Active when... Color
Fail power-up fault condition red
Access power-up ready state green
Data Mod In 1/2 output is active green
Clk Out 1/2 output is active green
Ctrl Out 1/2 output is active green
Ctrl In 1/2 logic level is detected green
P & N 1/2 output is active green
Clk In signal is detected green
Ref Clk In signal is detected green
Ref Clk Out not used green
Aux In not used n/a
Clk Out output is active green
Trig Out output is active green
