Keysight M8040A High-Performance BERT Getting Started Guide 23
Introduction 1
M8045A Front Panel Input/Output Ports
Table 5 M8045A Front Panel Input/Output Ports
Clk Mod In input is active green
Sys Out A/Sys Out B output is active green
Sys In A/Sys In B logic state is detected green
Connector Name Active when... Color
The inputs of the M8045A module are sensitive to static electricity.
Therefore, take necessary anti-static precautions, such as wearing a
grounded wrist strap, to minimize the possibility of electrostatic damage.
Component Description
CLK Out1 • Low Jitter (~150fs) Clk out. Baud-rate / 1,2,4,8,16
• Same Jitter as Data out or clean clk
• Typ 1.5 V pp
CLK Out2 • Low Jitter (~150fs) Clk out. Baud-rate / 1,2,4,8,16
• Same Jitter as Data out or clean clk
• Typ 1.5 V pp
P and N P and N must be connected to M8057A remote head.
REMOTE HEAD 1, 2 Remote Head Control. This output provides power and control signals for the
remote head amplifier
DATA MOD IN 1, 2 This input is used for data out delay modulation by an external source.
