Keysight M8000 Series of BER Test Solutions Installation Guide 27
Installing Modules 2
Installing M8020A Module(s)
The M9505A AXIe chassis and M8020A module(s) will come in separate
shipments. This section shows how to carefully insert a module in an
empty slot of an M9505A AXIe chassis. The slots are identified by the slot
numbers written on the front panel of the chassis.
The procedures in this section are not required if your system is an
M8020A-BU1 or M8020A-BU2, which have their modules pre-installed.
If you plan to use the M9536A or M9537A AXIe Embedded Controller as
the host computer, then you must reserve slot 1 of the chassis for this
module’s installation.
• The instrument modules are not hot swappable. You must power
down the AXIe chassis and host PC before inserting, replacing, or
removing a module.
• The enclosure surface of the instrument module may become hot
during use. If you need to remove the module, first power down the
AXIe chassis, allow the module to cool, and then pull the module out
of the chassis.
