Keysight M8000 Series of BER Test Solutions Installation Guide 43
Installing Modules 2
Setting up the M8030A
The AXIe chassis accepts modules conforming to the single slot, 1U AXIe
standard. These include:
• AXIe instrument modules
• AXIe System Module (ASM)
• AXIe filler panels
If the M9514A AXIe chassis and M8030A module(s) come in separate
shipments, please go through this section which shows how to carefully
insert a module in an empty slot of an M9514A AXIe chassis. The slots are
identified by the slot numbers written on the front panel of the chassis.
The procedure described in this section is not required in case of a
bundled system wherein modules are pre-installed.
Slot 1 is reserved for M9536A or M9537A AXIe Embedded Controller.
The instrument modules are not hot swappable. You must power down
the AXIe chassis and host PC before inserting, replacing, or removing a
module. The enclosure surface of the instrument module may become
hot during use. If you need to remove the module, first power down the
AXIe chassis, allow the module to cool, and then pull the module out of
the chassis.
