42 Keysight M8000 Series of BER Test Solutions Installation Guide
2 Installing Modules
The following figure displays the M9537A Embedded Controller installed in
slot 1 of the M9505A AXIe chassis.
Figure 29 M9537A embedded controller with M8041A
Detailed information and user guide for the M9536A or M9537A
Embedded Controller module is available at:
www.keysight.com/find/M9536A
www.keysight.com/find/M9537A
The M9536A or M9537A Embedded Controller module will successfully connect
with M8020A only when installed in slot 1 of the M9505A chassis. Make sure
that you install the module in the M8020A before powering up the complete
setup.
You should not connect the M8020A to multiple operating host computers at
the same time. If you plan to use the M9536A or M9537A AXIe Embedded
Controller as the host computer, then do not connect an external host computer
to the M8020A.
