Keysight M8000 Series of BER Test Solutions Installation Guide 65
Installing Modules 2
The following figure displays the M9537A Embedded Controller installed in
slot 1 of the M9505A AXIe chassis.
Figure 46 M9537A embedded controller with M8045A and M8046A
Detailed information and user guide for the M9537A Embedded Controller
module is available at www.keysight.com/find/M9537A.
The M9537A Embedded Controller module will successfully connect with
M8040A only when installed in slot 1 of the M9505A chassis. Make sure that you
install the module in the M8040A before powering up the complete setup.
You should not connect the M8040A to multiple operating host computers at
the same time. If you plan to use the M9537A AXIe Embedded Controller as the
host computer, then do not connect an external host computer to the M8040A.
