Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide 23
Overview
General Safety Considerations
Many of the assemblies in this instrument are very susceptible to damage
from electrostatic discharge (ESD). Perform service procedures only at a
static-safe workstation and wear a grounding strap.
These troubleshooting instructions are for use by qualified
personnel. To avoid electrical shock, do not perform any
troubleshooting unless qualified.
The opening of covers or removal of parts is likely to expose
dangerous voltages. Disconnect the instrument from all voltage
sources before it is opened.
The following techniques related to ESD and static-safe
workstations should not be used when working on circuitry with a
voltage potential greater than 500 volts.
Keep fingers and all other objects away from the fans when the
signal generator is plugged in.
For the instrument to meet performance specifications and for accurate
self test results, allow a warm up period of 45 minutes within an
operational temperature range of 0 to 55 °C. For more information, refer to
the X-Series signal generator Data Sheets.
When a procedure instructs you to preset the signal generator, press the
Preset hardkey, not the User Preset hardkey.
