336 Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide
Assembly Replacement
Outer Cover
Outer Cover
Tools Required
— T-20 driver
Removal Procedure
Refer to Figure 15-1 for this procedure.
1. Disconnect the power cord.
2. Using the T-20 driver, loosen the two screws (1) and remove the strap
handle (2).
3. Using the T-20 driver, remove the two hole plugs (not shown in photo)
from the opposite side of the instrument.
4. Using the T-20 driver, remove the center screws from the four rear-panel
feet (3).
5. Remove the four bottom feet (4) from the cover by first removing the
locking keys and then lifting the tab and sliding the foot toward the tab.
6. Place the signal generator on its side.
7. Place one hand on the front panel, use the other hand to lift the rear of the
signal generator and slide the outer cover (5) off to remove it from the
frame.
Replacement Procedure
1. Reverse the order of the removal procedures.
2. Recommended torque for all screws is 21 in–lbs.
The RF connector can be easily damaged. Use extreme caution to not
damage the RF connector when lifting the rear of the signal generator.
When sliding the outer cover back on the signal generator keep fingers
away from the back of the front panel. They can get severely pinched.
