431 Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide
Functional Tests
Relative Frequency Range and Accuracy Check
10.Repeat step step 8 and step step 9 for all of the frequencies in the table
that are within the frequency range of your signal generator.
Troubleshooting Problems with the Frequency Accuracy Check
— Verify the cables are connected correctly.
— If you are using a frequency counter, verify that you are using the correct
channel for the frequencies you are measuring.
For frequencies <200 MHz, use Channel 3 on the frequency counter
(press Freq Ratio
until CH3: displays).
Table 17-1 Frequency Accuracy Limits
Frequency (MHz) Limit (Hz)
0.01 MHz ±1
0.1 MHz ±1
200 MHz ±1
300 MHz ±1
500 MHz ±1
1000 MHz ±1
2000 MHz ±1
3100 MHz ±1
6000 MHz ±1
