Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide 231
Micro-Deck Assembly
A7 Micro-Deck Assembly Overview
Instruments without option 1E1 still have the A7AT1 Attenuator installed in
them. They will always bypass all the internal attenuator sections.
Atten Setting
A7AT1 Section
5 dB 10 dB 20 dB 40 dB 40 dB
0 dB
5 dB X
15 dB X X
25 dB X X
35 dB X X X
45 dB X X
55 dB X X X
65 dB X X X
75 dB X X X X
85 dB X X X
95 dB X X X X
105 dB X X X X
115 dB X X X X X
