Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide 147
Troubleshooting
Maximum Power Out Check
10.If the power level measured is within 3 dB of the value expected the
Maximum Power Out Check has passed.
>5 GHz to 6 GHz +16 dBm +18 dBm
Table 6-6 N5173B, N5183B Maximum Power Level
(Option 513, 520)
Frequency Range Standard Option 1EA
9 kHz to 3.2 GHz +18 dBm +23 dBm
> 3.2 GHz to 13 GHz +18 dBm +20 dBm
>13 GHz to 20 GHz +15 dBm +19 dBm
Table 6-7 N5173B, N5183B Maximum Power Level
(Option 532, 540)
Frequency Range Standard Option 1EA
9 kHz to 3.2 GHz +14 dBm +21 dBm
> 3.2 GHz to 17 GHz +14 dBm +16 dBm
>17 GHz to 31.8 GHz +13 dBm +15 dBm
>31.8 GHz to 40 GHz +11 dBm +15 dBm
Table 6-5 N5181B, N5182B Maximum Power Level
Frequency Range Standard Option 1EA
