26 Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide
Overview
Service Equipment You Will Need
Service Equipment You Will Need
There are certain things that will be required to troubleshoot, adjust, and test
the X-Series Signal Sources. They include the following:
— Calibration Application Software
—Misc Test Equipment
Tools you will need
Figure 1-1 TORX Tool
Hand Tool Size
Pozi Driver #1
Nut Driver 7 mm
Nut Driver 9/16 inch
Nut Setter (8710-2546) 5/8 inch
Open-End Wrench 5/16 inch
Torque Driver - Adjustable Multi Bit
Torque Wrench - 10 inch-lbs 5/16 inch
TORX Driver T-8
TORX Driver T-10
TORX Driver T-20
