Keysight Technologies N5183B MXG Service Guide

Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide 291
Replacement Parts
Assemblies, Cables, and Hardware
A6A3, Power Switch Assembly A6 Front Panel Assembly 2 0515-1227 Flat Head M3 x 0.5
(6 mm)
T-10 9 in-lbs
A6A4 PCA, Keypad A6 Front Panel Assembly 9 0515-0430 Pan Head M3 x 0.5
(6 mm)
T-10 9 in-lbs
A6MP6, Front Panel Display Bracket A6 Front Panel Assembly 8 0515-0372 Pan Head M3 x 0.5
(8 mm)
T-10 9 in-lbs
A6MP7, Display Side Support A6 Front Panel Assembly 3 0515-0665 Pan Head M3 x 0.5
(14 mm)
T-10 9 in-lbs
W4 & W5 I/Q Input BNC Cables A6 Front Panel Assembly 2 2950-0035 Hex Nut n/a 9/16" 21 in-lbs
2 2190-0102 Lock Washer n/a n/a n/a
A7 Real Time BBG Assembly Main Chassis 8 0515-0664 Pan Head M3 x 0.5
(12 mm)
T-10 9 in-lbs
Real Time BBG Mounting Bracket Main Chassis 2 0515-0664 Pan Head M3 x 0.5
(12 mm)
T-10 9 in-lbs
A7A1 Real Time Aux. Power Supply Real Time BBG Mounting Bracket 4 0515-0372 Pan Head M3 x 0.5
(8 mm)
T-10 9 in-lbs
A7A1 Real Time Aux. Power Supply Cover Real Time BBG Mounting Bracket 4 0515-0372 Pan Head M3 x 0.5
(8 mm)
T-10 9 in-lbs
W10 Real Time Aux. Power Supply Cable Grounds Real Time BBG Mounting Bracket 2 0515-0372 Pan Head M3 x 0.5
(8 mm)
T-10 9 in-lbs
A7 Micro-Deck Assembly Main Chassis 6 0515-0664 Pan Head M3 x 0.5
(10 mm)
T-10 9 in-lbs
A7A1 ALC Control Board A7 Micro-Deck Assembly 8 0515-0374 Pan Head M3 x 0.5
(10 mm)
T-10 9 in-lbs
Main Chassis 3 0515-0374 Pan Head M3 x 0.5
(10 mm)
T-10 9 in-lbs
A7A2 20 GHz Multiplier A7 Micro-Deck Assembly 6 0515-0383 Pan Head M4 x 0.7
(16 mm)
T-20 21 in-lbs
Table 14-6 Attaching Hardware
Attach To Qty Part
Number
Type Size Tool Torque
