312 Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide
Replacement Parts
Assemblies and Cables
Cable Clamp, W6 Semi-Rigid Cable to A2 Vector BBG Assy (N5166B, N5172B,
N5182B)
1400-3461
W1, Ribbon Cable, A3 RF Assy P5 to A6A1 Front Panel Interface J10 N5180-60183
W4, Coaxial Cable, A6 Front Panel I Input to A2 Vector BBG Assy J15 N5180-60435
W5, Coaxial Cable, A6 Front Panel Q Input to A2 Vector BBG Assy J16 N5180-60435
W6, Semi-Rigid Cable, A3 RF Assy J5000 to A2 Vector BBG Assy P500 N5180-60436
W7, Semi-Rigid Cable, A3 RF Assy J2004 to A2 Vector BBG Assy P1 N5180-20187
W8, Semi-Rigid Cable, A2 Vector BBG Assy P2 to A3 RF Assy J2003 N5180-20188
W9, Semi Rigid Cable, A3 RF Assy J4000 to RF Output see Table 14-1
W10, Cable Harness, A1 Power Supply to A7A1 Real Time BBG Aux. Power
Supply Input
N5180-60437
W12, Cable Harness, A7A1 Real Time BBG Aux. Power Supply Output N5180-60181
Description Part Number
