Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide 73
Self Test
Running Self Test
704 Go to “Troubleshooting Self Test 704” on page 91
800 BB Analog Baseband Self Tests
801 - 804 Replace the A2 Vector Module
900 BB RF Self Tests
901 - 905 Go to “Troubleshooting Self Test 901 to 905” on page 92
1100 MW ALC Self Tests
1101 - 1104 Replace the A7 Micro Deck
1105 Go to “Troubleshooting Self Test 1105” on page 94
1106 - 1119 Replace the A7 Micro Deck
1200 MW Multiplier Self Tests
1201 - 1205 Replace the A7 Micro Deck
1300 MW Mod Filter Self Tests
1301 - 1304 Replace the A7 Micro Deck
1400 MW Doubler Self Tests
1401 & 1402 Replace the A7 Micro Deck
1500 RT Board Self Tests
1501 - 1512 Replace the A7 Real-Time BBG
Table 4-1 Self Tests
Self Test Failure Number Resolution
