SA (Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)
SA Mode Settings
Figure 9-3 Tune & Listen ON
In the graphic above, Tune & Listen ON with Tune Frequency is indicated by a
vertical bar (highlighted).
How to select Tune & Listen
—Press Measure 1
—Then Analog Demod Tune & Listen > Tune & Listen
This section contains the following:
“How to select Tune & Listen” on page 164
– “TnL AM SSB Gain” on page 165
“Tune Frequency” on page 165
“Listen Time” on page 166
“To select Listen Time:” on page 166
“Volume Control” on page 166
“Audio Demod ON and OFF” on page 167
“Setting the Marker Counter Gate Softkey” on
page 175
“Setting the Mkr->TuneFreq Softkey” on page 167
Keysight N9938-90003 User's Guide
