The first parameter in the NRDGS command is a numeric parameter that specifies
the number of readings made per trigger event. For example, to specify 5 readings
per trigger event.
Press:
The display shows:
The second parameter of the NRDGS command specifies the event that initiates
each reading. Since this is not a numeric parameter, a menu is available for this
parameter. Use the up or down arrow keys to cycle through the list of choices.
When the display shows:
Execute the command by pressing:
You have now selected five readings per trigger event. If you execute the TRIG
SGL command, for example, the multimeter will take five readings and then stop.
(The NRDGS command is discussed in detail in Chapter 4.)
Using the MENU keys
In addition to the configuration keys, the multimeter has an alphabetic command
menu that can be accessed using the shifted MENU keys labeled C, E, L, N, R, S,
and T. Each of these letters corresponds to the area you will enter into the
command menu. For example, to enter the menu with commands starting with T.
Press:
