6-10 Site Preparation
6 Power Requirements
E9905G Test System
Figure 6-4 shows the locations of the AC outlets in an E9905G test system with side
pod.
Figure 6-4 Location of AC outlets in E9905G (rotated, rear view)
Outlet 4
PDU
Outlet 3
Outlet 1
Outlet 2
Outlet 0
