Using the Oscilloscope 2
Keysight Infiniium 90000A Series Oscilloscopes User’s Guide 31
Front Panel Controls (Keys and Knobs) Overview
The Infiniium 90000A Series oscilloscope front panel gives you direct access to the
functions needed to perform the most common measurements, using a traditional
oscilloscope interface. Knobs and keys let you directly set vertical and horizontal
parameters. The front panel also has a set of LED indicators; by using these and
the display, you see the oscilloscope’s configuration at a glance.
The oscilloscope uses color consistently throughout the front panel and user
interface. For example, the color of the knob for channel 1 is the same color as the
waveform for channel 1. All the configuration items and values related to channel
1 are displayed in the same color.
Figure 11 Infiniium 90000A Series oscilloscope front panel
Marker and
Measurement Controls
Vertical controls
Acquisition and
general controls
Horizontal
controls
Trigger
controls
