• Frame and Signal — a symbolic frame value and a signal value.
Symbolic frames, signals, and values are defined in the LIN description file.
A frame is the symbolic name for a LIN frame ID, a signal is the symbolic name
for a bit or set of bits within the LIN data, and a value can be a symbolic
representation of the signal bit values or it can be a decimal number with units.
LIN Serial Decode
To set up the oscilloscope to capture LIN signals, see “Setup for LIN Signals" on
page 407.
For details about using the LIN Bits Menu softkeys, press and hold the softkey in question to
display the built-in help.
For LIN decode information see “LIN Serial Decode" on page 411.
