Keysight InfiniiVision 3000T X-Series Oscilloscopes User's Guide 5
• 2- and 4-channel digital storage oscilloscope (DSO) models.
• 2+16-channel and 4+16-channel mixed-signal oscilloscope (MSO) models.
An MSO lets you debug your mixed-signal designs using analog signals and
tightly correlated digital signals simultaneously. The 16 digital channels have a
1.25 GSa/s sample rate, with a 200 MHz toggle rate.
• 8.5 inch WVGA touchscreen display. The touchscreen makes the oscilloscope
easier to use:
• You can "touch" inside alpha-numeric keypad dialogs to enter file, label,
network, and printer names, etc., instead of using softkeys and the
Entry knob.
• You can drag a finger across the screen to draw rectangular boxes for
zooming in on waveforms or setting up Zone triggers.
• You can touch the blue menu icon in the sidebar to display information or
control dialogs. You can drag (undock) these dialogs out of the sidebar, for
example, to view cursor values and measurements at the same time.
• You can touch other areas of the screen as substitutes for using front panel
keys, softkeys, and knobs.
• Interleaved 4 Mpts or non-interleaved 2 Mpts MegaZoom IV memory for the
fastest waveform update rates, uncompromised.
• All knobs are pushable for making quick selections.
• Trigger types: edge, edge then edge, pulse width, pattern, OR, rise/fall time,
Nth edge burst, runt, setup & hold, video, NFC, and zone.
• Serial decode/trigger options for: CAN/CAN FD/LIN, CXPI, FlexRay, I
2
C/SPI,
I
2
S, Manchester/NRZ, MIL-STD-1553/ARINC 429, SENT, and UART/RS232.
There is a Lister for displaying serial decode packets.
• Dedicated [FFT] key and FFT waveform math function.
• Two additional math waveforms: add, subtract, multiply, divide, d/dt,
integrate, FFT (Magnitude), FFT (Phase), Ax+B, square, square root, absolute
value, common logarithm, natural logarithm, exponential, base 10 exponential,
low pass filter, high pass filter, averaged value, smoothing, envelope, magnify,
maximum, minimum, peak-peak, max hold, min hold, measurement trend,
chart logic bus timing, and chart logic bus state.
• Reference waveform locations (2) for comparing with other channel or math
waveforms.
• Many built-in measurements and a measurement statistics display.

Keysight MSOX3104T Specifications

General

Brand	Keysight
Model	MSOX3104T
Category	Test Equipment
Language	English
