28 N1000A Quick Start Guide
2 Installing the N1000A
Step 7. Turn On the Instrument
1 Press the ON/Standby switch.
Figure 11 Location of ON/Standby Button
2 Wait while the instrument boots up. During the process, you will be asked to
accept the Windows 10 End User License Agreement (EULA). Once accepted
the N1000A will continue to configure itself.
3 After the instrument boots up, the FlexDCA oscilloscope application appears
and looks similar to the following figure.
Figure 12 FlexDCA Oscilloscope Application
Before switching on this instrument, make sure the supply voltage is in the specified
range. Refer to Table 2 on page 22.
