1 Specifications and Characteristics
42 Keysight N1913/1914A Service Guide
Rear Panel Inputs and Output Connections
Line power
Recorder output(s)
Analog 0 to 1 V, 1 k
Ω output impedance, BNC connectors
GPIB
USB 2.0
10/100Base-T LAN
Interfaces allow communication with an external controller
Trigger input (optional)
Input has TTL compatible logic levels and uses a BNC
connector
Trigger out (optional)
Output provides TTL compatible logic levels and uses a BNC
connector
Ground Binding post, accepts 4 mm plug or bare wire connection
USB host (optional) To connect U2000 Series power sensors
VGA out (optional)
Standard 15-pin VGA connector, allows connection of external
VGA monitor
Input voltage range
100 – 240 Vac
100 – 120 Vac
Automatic voltage selection
Fluctuations not exceeding ±10%
Input frequency range
50 – 60 Hz (100 to 240 Vac)
400 Hz (100 to 120 Vac)
Power requirement 70 VA (maximum)
