Keysight N777-C Series Tunable Laser Family User’s Guide 35

Getting Started 2

USB Interface

The instrument is a USB device, with a USB Type-B connector which is

available on the rear side of the instrument.

NOTE

It is recommended to use the Keysight IO Libraries Suite to enable

instrument communication for a variety of development environments.

It is available at: http://keysight.com/find/iolibs

USB Type-B Connector

Default Chapter3
- Safety Summary3
- Instrument Markings4
- South Korean Class a EMC Declaration5
- Compliance and Environmental Information5
- Declaration of Conformity5
- Table of Contents7
