76 Keysight N777-C Series Tunable Laser Family User’s Guide
4 N777-C Web User Interface Reference
To perform the save/recall operation:
1Click on the Save/Recall tab.
2 To save a file, click on Export button. The web interface settings will be
saved as an XML file in your PC.
3 To recall a previously saved file, click on Upload your XML file here
button. A Windows Open dialog will appear. Locate the target file and
click Open. The settings will be loaded in the instrument.
Logging In/Out of the N777-C Web Interface
The login screen allows the authorized users to control the N777-C
instruments. When the users type in their password and click Enter, their
credentials are validated and if correct they are logged in.
If you want to create a new password or change an existing password,
click on Change Password button. For details, see How to Create/Change
the Password? on page 77.
To log out the N777-C web interface, click on Log out icon available on the
top right of the web interface.
