Keysight N777-C Series Tunable Laser Family User’s Guide 75
N777-C Web User Interface Reference 4
How to Identity a Particular instrument?
Sometimes, you have many instruments mounted on the rack. In this
situation, it becomes difficult to identify a particular instrument which are
currently connected.
To identify a particular instrument, select the check-box Enable front
panel identification indicator available on the N777-C Home tab. The
Status LED on the front panel of the connected instrument will start
flashing.
How to Capture an Image of the Graph?
The Get Image tab on the N777-C web interface allows you to capture the
current screen of the Control Instrument tab and save it as a PNG image.
The captured image is saved in the “Downloads” folder.
How to Save/Recall the Web Interface Settings?
The Save/Recall tab on the N777-C web interface allows you to save and
recall the web interface settings.
You can only capture the screen if you are in the Control Instrument tab.
