Getting Started
Remotely Operating the Analyzer
6
Connecting the Analyzer via the LAN Port
No extra driver is required to connect the analyzer via the
LAN port to a PC. All you need is the Keysight IO libraries
suite in the Product CD Help Kit. Or refer to the link below
to download the IO libraries suite:
http://www.keysight.com/find/iolib
Please refer to the following steps to finish the connection:
1 Switch on the analyzer.
2 Connect the spectrum analyzer to a PC with a LAN cable.
3 Press [SYS] > {Setting} > {IP Admin} > {IP address} to set IP
address for the instrument. For example, set “10.0.0.5” as the
IP address for the instrument. Press {Apply} as
4 Run Keysight Connection Expert in IO libraries suite.
Right- click on the LAN (TCPIP0) icon, select “Add Instrument’
in the pop- up menu. The “Add LAN Instruments” window
displays for the IP configuration.
5 Select “Add Address”, check “Use IP Address” in the window
and input the IP address as the instrument IP address you
set before.
