12 Keysight P937xA PXIe Service Guide
Safety and Regulatory Information
Electrostatic Discharge Protection
1-
Electrostatic Discharge Protection
Electrostatic discharge (ESD) can damage or destroy electronic components.
Use a static-safe work station to perform all work on electronic assemblies.
Figure 1-1 on page 1-12 shows a static-safe work station using two types of
ESD protection: conductive table-mat and wrist-strap combination, and
conductive floor-mat and heel-strap combination. Both types, when used
together, provide a significant level of ESD protection. Of the two, only the
table-mat and wrist-strap combination provides adequate ESD protection
when used alone. To ensure user safety, the static-safe accessories must
provide at least 1 meg-ohm of isolation from ground.
Figure 1-1 ESD protection setup
Unpack the P937xA network analyzer from the shipping containers. Keep the
black plastic port protectors and the shipping containers for possible reuse.
Most causes of instrument failure can be avoided if you will apply the
information in this section. PLEASE READ!
Do NOT use these techniques for a static-safe work station when
working on circuitry with a voltage potential greater than 500 volts.
