Removal and Replacement Procedures
Information in This Chapter
Keysight P937xA PXIe Service Guide
5 Removal and Replacement Procedures
Information in This Chapter
This chapter contains procedures for removing and replacing the major
assemblies of your Keysight USB Streamline network analyzer.
STOP!!! Please read all content before proceeding with this repair
procedure. This repair must be done at a service center! If you think you
may not be qualified to do the work, or need advice, contact Keysight.
Refer to “Keysight Support, Services, and Assistance” on page 22.
Section Title Summary of Content
Start Page
Electrostatic Discharge (ESD)
Protection
Information pertaining to ESD protection. page 62
Connector Replacement Procedure A procedure for replacing the Streamline connectors. page 63
Front Panel Replacement Procedure Procedure for replacing the front panel. page 65
Chassis Replacement Procedure Procedure for replacing the USB-VNA chassis. page 68
Module Replacement Procedure Procedure for replacing the module inside the
USB-VNA.
page 71
Post-Repair Procedures A table for the proper tests, verifications and
adjustments to perform on your analyzer after repair.
page 73
The hardware does not support “hot-swap” (changing network analyzer
modules while power is applied to the chassis) capabilities. Before
installing or removing a module to/from the chassis, power-off the chassis
to prevent damage to the module.
