Chapter 2: Front panel programming
P/N 3102351-EN • REV 005 • ISS 28DEC18 47
Event
CID
Loop 1 map fault
331
Loop 1 card fault (disable)
500
Loop 1 card fault (trouble)
333
Loop 1 Uncfgrd alarm (disable)
500
Loop 1 Uncfgrd alarm
(active) 110
Loop 1 Uncfgrd trbl (disable)
500
Loop 1 Uncfgrd trbl (trouble)
331
Loop 1 map mismatch
331
Loop 1 over limits
331
Loop 1 mapping
000
Loop 2 device 000
018
Loop 2 initialization
000
Loop 2 fault (disable)
500
Loop 2 fault (trouble)
331
Loop 2 map fault
331
Loop 2 card fault (disable)
500
Loop 2 card fault (trouble)
333
Loop 2 Uncfgrd alarm (disable)
500
Loop 2 Uncfgrd alarm (active)
110
Loop 2 Uncfgrd trbl (disable)
500
Loop 2 Uncfgrd trbl (trouble)
331
Loop 2 map mismatch
331
Loop 2 over limits
331
Loop 2 mapping
000
Loop 3 device 000
028
Loop 3 initialization
000
Loop 3 fault (disable)
500
Loop 3 fault (trouble)
331
Loop 3 map fault
331
Loop 3 card fault (disable)
500
Loop 3 card fault (trouble)
333
Loop 3
Uncfgrd alarm (disable) 500
Loop 3 Uncfgrd alarm (active)
110
Loop 3 Uncfgrd trbl (disable)
500
Event
CID
Loop 3 Uncfgrd trbl (trouble)
331
Loop 3 map mismatch
331
Loop 3 over limits
331
Loop 3 mapping
000
Loop 4 device 000
038
Loop 4 initialization
000
Loop 4 fault (disable)
500
Loop 4 fault (trouble)
331
Loop 4 map fault
331
Loop 4 card fault (disable)
500
Loop 4 card fault (trouble)
333
Loop 4 Uncfgrd alarm (disable)
500
Loop 4 Uncfgrd alarm (active)
110
Loop 4 Uncfgrd trbl (disable)
500
Loop 4
Uncfgrd trbl (trouble) 331
Loop 4 map mismatch
331
Loop 4 over limits
331
Loop 4 mapping
000
Monitor active
140
NAC test
600
NAC1 trouble
321
NAC2 trouble
322
NAC3 trouble
326
NAC4 trouble
327
NAC1 disable
521
NAC2 disable
522
NAC3 disable
526
NAC4 disable
527
Net rcvr1 comm fault
354
Net rcvr2 comm fault
354
Net rcvr3 comm fault
354
Net rcvr4 comm fault
354
Net rcvr5 comm fault
354
Net rcvr6 comm fault
354
Net rcvr7 comm fault
354
