KINSHOFER TR07 - Page 17

Technical Information
30.03.2020
TR07-TR11-TR14-TR19-TR25
17
Type
TR14
TR19
TR25
DF10
DF4
CSP
DF10
DF4
CSP
DF10
DF8
CSP
Operating weight
[t]
10 - 14
14 - 19
18 - 25
max. breakout force
(ISO)
[kN]
110
150
170
Max. bucket width
[mm]
1600
1700
2000
Weight (incl. UB,
excl. LQC)
approx.
[kg]
400
540
610
Tilting angle
[°]
2 x 50
2 x 50
2 x 50
Tilting torque
[kNm]
26
34
44
Rotational speed
[1/min]
8.5 @ 45 l/min
8.5 @ 50 l/min
8.5 @ 60 l/min
Rotation torque
Nm
6000 @ 360° continuous
7000 @ 360° continuous
8500 @ 360° continuous
Recom. pump capacity
[l/min]
80 - 160
100 - 180
120 - 200
Recom. tilting/rotating
oil flow
[l/min]
40 / 45
40 / 45
80
60 / 50
60 / 50
100
70 / 70
70 / 70
120
Max. oil flow, extra
function 1/2
SD*
[l/min]
70 / 30
70 / 30
70 / 30
70 / 30
70 / 30
70 / 30
70 / 30
70 / 30
70 / 30
HF*
[l/min]
70 /120
-
70 /120
70 /120
-
70 /120
70 /150
-
70 /150
Max. hydraulic
pressure
Rotation
[MPa]
20
20
-
20
20
-
20
20
-
Tilt
[MPa]
30
30
30
30
30
30
30
30
30
Max. back pressure
[MPa]
2.5
2.5
2.5
Hose sizes
SD*
[in]
5/8
5/8
3/4
HF*
[in]
3/4
3/4
1
Transmission oil
quantity
[l]
1.5
2.0
2.5
Rotary feedthrough:
Ducts, extra function
4
4
4
Rotary feedthrough:
Ducts, quick coupler
2 2 2
Rotary feedthrough:
Leak oil duct
1
1
1
Electric rotary
feedthrough (optional)
Ducts x[A]
12 x 0.5
12 x 0.5
12 x 0.5
Max. load capacity
(WLL)
Load hook (optional)
[t]
5
5
10
Max. load capacity
(WLL)
Lifting eye (optional)
[t]
8.5
8.5
12
Lifting eye (optional)
Shackle size
[in]
1
1
1 1/4
SD* = Standard rotary feedthrough; HF* = High-Flow rotary feedthrough
The tilt and rotation torque values only apply for the respective maximum permissible pressures.
