Installation and initial operation
4.6. Troubleshooting - TR NOX III control systems
With the CSP, DF4, DF10 and DF10 control systems with upgrade kit,
the following functional faults may occur:
» No function.
CSP
faulty:
» Plug connection not
connected to the outrigger.
» Defective cable, solenoid coil
» Connect plug connection.
» Repair cable, solenoid coil or
valve,
replace if necessary.
» Control system is not working:
» Plug connection not
connected to the display.
» Check plug connections on the
display and
» Hammer valve does not open.
» Activate additional hydraulics on
the
DF4
not be switched.
» Activate additional hydraulics on
the
DF10
not be switched.
» Activate additional hydraulics on
the
DF10 with
upgrade kit
not be switched.
» Activate additional hydraulics on
the
» Does not
» tilt or tilts
» too slowly.
CSP
faulty:
» Plug connection not
connected to the display.
» Defective cable, solenoid coil
» Connect plug connection.
» Repair cable, solenoid coil or
valve,
replace if necessary.
» No electrical contact
on the valve.
» Check valve connector under the
covering
» Faulty configuration
of the control system.
» Configure control system.
» Counterbalance valve
incorrectly adjusted.
» Re-adjust
counterbalance valve.
DF4
faulty:
» Plug connection not
connected to the display.
» Defective cable, solenoid coil
» Connect plug connection.
» Repair cable, solenoid coil or
valve,
replace if necessary.
» No electrical contact
on the valve.
» Check valve connector under the
covering
» Counterbalance valve
incorrectly adjusted.
» Re-adjust
counterbalance valve.
» Oil flow rate not
sufficient.
» Optimise dimensioning of the
hoses.
» Check hydraulic connections
and couplers for
