5.4. Working with attachment points
The attachment points (load hook and lifting eye) are available as accessories.
• Use only with carrier machines that are equipped with load safety devices
per EN 474-5:2006+A2:2012.
• Payload table at driver's station
• Overload warning device
• Hose rupture safety device on lift and dipper arm cylinder
• Observe the load bearing capacity of the carrier machine.
• Observe the operating manual for the carrier machine.
• Observe the working load limit of the attachment points.
• Make sure the attachment points are loaded correctly.
• Only use approved lifting attachments / slings.
• Lift the load slowly and carefully.
• Observe the stipulated safety distances.
Load lifting examples with load hook
Load lifting examples with lifting eye
Load lifting - lifting eye
NOTICE
All possibilities that are not shown are non-intended uses and are prohibited.
